Globe Valves
NPS 2"-24" for Class 150-600; NPS 2"-12" for Class 900 and above
Globe valves are heavy duty, outside screw and yoke type, bolted bonnet, rising stem and rising handwheel type. These valves are highly efficient for service requiring frequent operation and throttling.
Characteristics
Design Features: • Stem packing is designed for optimum control of fugitive emission leakage to the atmosphere and is assured by the polished finish stem sealing area; • Disc is ground and lapped for better finish and sealing. The disc is integrally guided to assure true alignment between disc and valve body.
Size range: 2” to 24” for Class 150-600; 2” to 12” for Class 900 and above
Pressure Class: ANSI 150-2500
Temperature range: -60 °C to +650 °C
Materials: ASTM, UNS, AISI, NACE MR-01-03
Carbon, alloy and stainless steels, duplex steels, special alloys CRA weld overlays are available. All materials conform to NACE MR-01-75 upon requirement.
Flanges:
ASME B16.5
Buttweld: ASME B16.25
